We understand the automotive industry

Feeding technology for the automotive industry

Valve locks or valve springs in motor construction, screws or sheet metal parts in body construction, or contacts in battery assembly… Our feeding technology ensures the efficient and precise supply of series components to the robot or assembly line.

The challenges

The automotive industry has high requirements for availability and safety, as well as smooth and continuous plant operation. Automation solutions must also work efficiently throughout their entire life cycle.

Our expertise

We have decades of experience in the automotive industry and are very familiar with the requirements and specifications of our customers. We comply with safety and industry standards, and the high availability and robustness of our lines enables efficient process optimization in the production process.

Body construction

Below is just a selection of parts for which we have already designed and produced feed devices.

foam models transported by the automotive feeding solutions by Köberlein & Seigert

Foam models

150x85x30 mm

Information

Sorting parts: Foam models



Our solution:

Single-lane feeding device with a storage conveyor, stepfeeder and sorting track for positioning and separation for correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
2 parts per minute

Eine Befestigungsklammer die mit Hilfe der Zuführtechnik von Köberlein & Seigert transportiert wird

Fastening clips

15x35x45 mm

Information

Sorting parts: Fastening clips

Our solution:

Single-lane feeding device with a vibrating conveyor, stepfeeder and sorting track for positioning and separation for correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
5 parts every 97 seconds

Ein Karosserieteil das mit Hilfe der Zuführtechnik von Köberlein & Seigert transportiert wird

Body parts

200x130x90 mm

Information

Sorting parts: Body parts

Our solution:

Feeding device with manual placement, from which a single-lane sorting track feeds the parts into the separation process. Separation correctly transfers the parts to the downstream production step.

Performance:
1 part per minute

fasteners transported by the automotive feeding solutions by Köberlein & Seigert

Fasteners

Washer ø=20 mm; H=10 mm

Information

Sorting parts: Fasteners

Our solution:

Single-lane feeding device with a stepfeeder, sorting track and separation. Integrated fan blower technology correctly transfers the parts in a catching station to the downstream production step.

Performance:
8 parts every 117 seconds

Body construction

Below is just a selection of parts for which we have already designed and produced feed devices.

foam models transported by the automotive feeding solutions by Köberlein & Seigert

Foam models

150x85x30 mm

Information

Sorting parts: Foam models



Our solution:

Single-lane feeding device with a storage conveyor, stepfeeder and sorting track for positioning and separation for correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
2 parts per minute

fasteners transported by the automotive feeding solutions by Köberlein & Seigert

Fasteners

Washer ø=20 mm; H=10 mm

Information

Sorting parts: Fasteners

Our solution:

Single-lane feeding device with a stepfeeder, sorting track and separation. Integrated fan blower technology correctly transfers the parts in a catching station to the downstream production step.

Performance:
8 parts every 117 seconds

Eine Befestigungsklammer die mit Hilfe der Zuführtechnik von Köberlein & Seigert transportiert wird

Fastening clips

15x35x45 mm

Information

Sorting parts: Fastening clips

Our solution:

Single-lane feeding device with a vibrating conveyor, stepfeeder and sorting track for positioning and separation for correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
5 parts every 97 seconds

Ein Karosserieteil das mit Hilfe der Zuführtechnik von Köberlein & Seigert transportiert wird

Body parts

200x130x90 mm

Information

Sorting parts: Body parts

Our solution:

Feeding device with manual placement, from which a single-lane sorting track feeds the parts into the separation process. Separation correctly transfers the parts to the downstream production step.

Performance:
1 part per minute

E-mobility

Below is just a selection of parts for which we have already designed and produced feed devices.

aluminum profile parts transported by the automotive feeding solutions by Köberlein & Seigert

Aluminum profile parts

130×70/90×50 mm

Information

Sorting parts: Aluminum profile parts



Our solution:

Single-lane feeding device with a storage conveyor, stepfeeder and sorting track for positioning and correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
4 parts every 80 seconds

short sleeves transported by the automotive feeding solutions by Köberlein & Seigert

Sleeves (short)

External ø=40 mm; H=20 mm

Information

Sorting parts: Sleeves (short)

Our solution:

Single-lane feeding device with a stepfeeder and sorting track for positioning and separation for correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
2 parts per minute

car consoles transported by the automotive feeding solutions by Köberlein & Seigert

Consoles

50x80x80 mm

Information

Sorting parts: Consoles

Our solution:

Single-lane feeding device with a storage conveyor, stepfeeder and sorting track for positioning and separation for correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
1 part every 120 seconds

long sleeves transported by the automotive feeding solutions by Köberlein & Seigert

Sleeves (long)

External ø=30 mm; H=45 mm

Information

Sorting parts: Sleeves (long)

Our solution:

Single-lane feeding device with a storage conveyor, stepfeeder and sorting track for positioning and separation for correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
7 parts per minute

E-mobility

Below is just a selection of parts for which we have already designed and produced feed devices.

aluminum profile parts transported by the automotive feeding solutions by Köberlein & Seigert

Aluminum profile parts

130×70/90×50 mm

Information

Sorting parts: Aluminum profile parts



Our solution:

Single-lane feeding device with a storage conveyor, stepfeeder and sorting track for positioning and correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
4 parts every 80 seconds

long sleeves transported by the automotive feeding solutions by Köberlein & Seigert

Sleeves (long)

External ø=30 mm; H=45 mm

Information

Sorting parts: Sleeves (long)

Our solution:

Single-lane feeding device with a storage conveyor, stepfeeder and sorting track for positioning and separation for correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
7 parts per minute

short sleeves transported by the automotive feeding solutions by Köberlein & Seigert

Sleeves (short)

External ø=40 mm; H=20 mm

Information

Sorting parts: Sleeves (short)

Our solution:

Single-lane feeding device with a stepfeeder and sorting track for positioning and separation for correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
2 parts per minute

car consoles transported by the automotive feeding solutions by Köberlein & Seigert

Consoles

50x80x80 mm

Information

Sorting parts: Consoles

Our solution:

Single-lane feeding device with a storage conveyor, stepfeeder and sorting track for positioning and separation for correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
1 part every 120 seconds

Motor assembly

Below is just a selection of parts for which we have already designed and produced feed devices.

valve locks transported by the automotive feeding solutions by Köberlein & Seigert

Valve locks

Ø=10 mm; L=5 mm

Information

Sorting parts: Valve locks



Our solution:

Four-lane feeding device with a stepfeeder, sorting track and separation. Integrated 8-hose fan blower correctly transfers the parts to the downstream production step.



Performance:
64 parts per minute

valve stem seals transported by the automotive feeding solutions by Köberlein & Seigert

Valve stem seals

External Ø=12 mm; H=10 mm

Information

Sorting parts: Valve stem seals

Our solution:

Single-lane feeding device with a stepfeeder, sorting track with integrated incorrect part ejection for positioning and correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
16 parts per minute

valve fit rings transported by the automotive feeding solutions by Köberlein & Seigert

Valve fit rings

External Ø=30 mm; H=5 mm

Information

Sorting parts: Valve fit ring

Our solution:

Single-lane feeding device with a storage conveyor, stepfeeder and sorting track for positioning and correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
300 parts per minute

valve springs transported by the automotive feeding solutions by Köberlein & Seigert

Valve springs

External ø=20 mm; Internal ø=15 mm; L=50 mm

Information

Sorting parts: Valve springs

Our solution:

Double-lane solution comprising two parallel feeding devices, each with a storage conveyor, stepfeeder and sorting track for positioning and separation for correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
32 parts per minute

Motor assembly

Below is just a selection of parts for which we have already designed and produced feed devices.

valve locks transported by the automotive feeding solutions by Köberlein & Seigert

Valve locks

Ø=10 mm; L=5 mm

Information

Sorting parts: Valve locks



Our solution:

Four-lane feeding device with a stepfeeder, sorting track and separation. Integrated 8-hose fan blower correctly transfers the parts to the downstream production step.



Performance:
64 parts per minute

valve springs transported by the automotive feeding solutions by Köberlein & Seigert

Valve springs

External ø=20 mm; Internal ø=15 mm; L=50 mm

Information

Sorting parts: Valve springs

Our solution:

Double-lane solution comprising two parallel feeding devices, each with a storage conveyor, stepfeeder and sorting track for positioning and separation for correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
32 parts per minute

valve stem seals transported by the automotive feeding solutions by Köberlein & Seigert

Valve stem seals

External Ø=12 mm; H=10 mm

Information

Sorting parts: Valve stem seals

Our solution:

Single-lane feeding device with a stepfeeder, sorting track with integrated incorrect part ejection for positioning and correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
16 parts per minute

valve fit rings transported by the automotive feeding solutions by Köberlein & Seigert

Valve fit rings

External Ø=30 mm; H=5 mm

Information

Sorting parts: Valve fit ring

Our solution:

Single-lane feeding device with a storage conveyor, stepfeeder and sorting track for positioning and correct transfer to the downstream production step. Incorrectly positioned parts are automatically returned to the conveying process.

Performance:
300 parts per minute
